48/60/72V 1500W Brushless Electric Bike Hub Motor E-bike BLDC Motor

48-72V 1500W Electric Bike Hub Motor E-bike Brushless Motor Rear Wheel Drive with Drum Braking System
This is an 1500W 48-72V Brushless Hub Motor for E-bike used with various types of bikes in Pakistan like CD-70, CG-125, GS-150, YBR, YBZ, RP-100 etc.
The motor has the connection wires for the hall sensor and temperature controller making it more easy to control. One can use this Hub motor in Self-balancing Car, Electric Scooter, Skateboard, E-bike, ATV, Electric Roller, DIY Conversion Kit, E-Scooter, etc.
This is an easy to install hub motor with plug and drive wiring to controller, that makes it convenient to install. The elegant design and black color of the motor gives you bike a beautiful look. The copper winding of the motor makes it energy-efficient
With a wide input voltage range of 48-72V, make it compatible with all types of lithium ion and lifePo4 battery packs.
Features of 1500W Brushless Hub DC Motor:

Elegant Black color with silver lining
Wide range of operating voltage 48-72V
Copper winding for energy efficiency
Compatible with almost all bikes
Spoke design makes it compatible with both front and rear wheel application
Slim design that can fit in all kind of bikes
With drum braking system
High torque to lift heavy weight and keep the speed constant on inclined surfaces
Compatibility with 16-28 inch wheels that covers almost all types of bikes available in Pakistan
Highly efficient, for more mileage
10in wheel hub motor can be used for electric motorcycle, electric off-road vehicle, electric bicycle, scooter, go kart, etc.

Specification:

Nominal Voltage (V): 48-72 V
Nominal Power (W): 1500 W
Wheel size (inch): 16-28 inch
Nominal Speed (km / h): 55-65 km/h
Weight (KG): 10kg
Spoke: 36 hole spoke 12G / 13G
Position: Rear
Build: Gear
Dropout / Open Size (mm): 26cm / 10 inches
Thickness: 8cm
Spokes gap: 3.4cm
Magnet Poles (2 p): 10
Type of brake: Drum brake
Cabling Route: Center
Operating temperature (ºC): -20-45 ºC
Efficiency (%): 82%
Max, Efficiency (%): 86%
Noise Grade (DB) <55
IP Grade: IP65
Salt Spray Test Standard (h) 96
Surface Color: Black
